Sketch of Solids

We can make a sketch of solids, especially cube and cuboid, using an
isometric dot paper. Observe the drawing of the cube given below.

In a similar way, we can draw a cuboid also.

View of an Object

We see several 3-D objects in our surroundings. When we observe an
object, we are able to see only a particular portion of the object not an

all round view.

When we look at an object from its top, it is called the plan of the object;

from its front, it is called the elevation and from its side, it is called the

side view of the object.

→

Elevation Side view Plan
